Cua -Coled Dej Chiller rau Laser Cutter 8000W
Hanli chiller HL-8000-QG2/2 tuaj yeem tiv thaiv cov fiber ntau laser thiab optics los ntawm overheating, uas yog ib qho tseem ceeb tshwj xeeb tshaj yog thaum ua hauj lwm ntawm lub zog siab mus txog 8KW. Ob chav ntsuas kub tswj Circuit Court tsim kom ntseeg tau tias ob qho tib si tuaj yeem ua kom txias tau zoo, uas tuaj yeem pab tau ...
- Khoom Taw qhia
Hanli chiller HL-8000-QG2/2 tuaj yeem tiv thaiv cov fiber ntau laser thiab optics los ntawm overheating, uas yog ib qho tseem ceeb tshwj xeeb tshaj yog thaum ua hauj lwm ntawm lub zog siab mus txog 8KW. Lub tshuab hluav taws xob tswj hluav taws xob ob lub ntsuas hluav taws xob ua kom ntseeg tau tias ob qho tib si tuaj yeem ua kom txias tau zoo, uas tuaj yeem pab tswj kev ua haujlwm tag nrho thiab kev ua haujlwm ntev ntawm lub tshuab fiber ntau. Tsis tas li ntawd, cov tub yees hluav taws xob siv hluav taws xob siv cov solenoid li qub kom tsis txhob nquag pib thiab nres lub voj voog ntawm lub tshuab compressor, uas tuaj yeem pab txuas ntxiv nws lub neej kev pab cuam. Thaum kawg, Nws muab cov kev ua kom txias txias kom pab ua kom lub tshuab fiber ntau ua haujlwm zoo thiab muaj kev ntseeg siab nyob rau lub sijhawm ntev.
|
|
Uint |
|
HL-8000-QG2/2 |
|
Voltage & Zaus |
3p 380V / 50Hz |
||
|
Rated zog |
kW |
9.7 |
|
|
siab tshaj tam sim no |
A |
18.5 |
|
|
Lub peev xwm txias |
kW |
15.2 |
|
|
Compressor zog |
kW |
4.15 |
|
|
Hluav taws xob cua sov |
kW |
1.6/1.4 |
|
|
Lub tshuab fais fab |
kW |
1.85 |
|
|
Ntxuam zog |
kW |
0.75 |
|
|
Qhov siab tshaj plaws cua ntim ntawm kiv cua |
m³/h |
8400 |
|
|
Rated Flow ntawm qhov kub qis kawg |
L / min |
80-88 |
|
|
Rated siab ntawm qhov kub qis kawg |
bar |
4.0 |
|
|
Qhov siab tshaj plaws ntawm qhov kub qis kawg |
bar |
5.2 |
|
|
Dimensions ntawm qhov kub siab kawg interface |
G1-Φ25mm Pagoda pob qij txha |
||
|
Dej kub qhov chaw ntawm qhov kub tsawg kawg |
degree |
21-32 |
|
|
Rated Flow ntawm qhov kub siab kawg |
L / min |
2.3 |
|
|
Rated siab ntawm qhov kub siab kawg |
bar |
4.0 |
|
|
Qhov ntev ntawm qhov kub siab kawg interface |
G1/2-Φ12mm ceev connector |
||
|
Dej kub qhov chaw ntawm qhov kub siab kawg |
degree |
26-35 |
|
|
Dej kub tswj qhov tseeb |
degree |
22-29.5 |
|
|
Dej Tank |
L |
55 |
|
|
Kev thov ib puag ncig |
degree |
-20-40 |
|
|
Coolant |
R32 |
||
|
Lub suab nrov |
dB (A) |
≈75 |
|
|
Tshuab dimension |
mm |
70 |
|
|
Net nyhav |
kg |
610×665× 1000 |
|
|
Packing dimension |
mm |
76 |
|
|
Qhov hnyav tag nrho |
kg |
725×670×1035 |
|
|
Haum cua txias nruab nrab |
Cov dej ntshiab, glycol daws (concentration Tsawg dua lossis sib npaug li 30%) |
||
Cim npe nrov: cua-cua txias dej chiller rau laser cutter 8000w, Tuam Tshoj cua- txias dej chiller rau laser cutter 8000w manufacturers, hoobkas
